GM7

Distinctive Angular Geometry

Support GPU length up to 420 mm
Support CPU cooler height up to 180 mm
Support installing of up to 9 x 120 mm fans
Support 360 radiator at top
Supports BTF motherboards with rear connectors for a cleaner look and easier cable management
Angular design elements on the front bottom section provides a distinctive signature look

Color

MODEL

GM7

STRUCTURE DIMENSIONS (L x W x H)

440 x 235 x 454 mm

PRODUCT DIMENSIONS (L x W x H)

446 x 235 x 483 mm

PACKAGE DIMENSIONS (L x W x H)

550 x 290 x 515 mm

STRUCTURE THICKNESS

0.7 mm

MATERIALS

SPCC, tempered glass, plastic

FORM FACTOR

ATX / M-ATX / ITX

DRIVE BAYS

3.5" HDD: 1, 2.5" SSD: 1

CPU COOLER MAX HEIGHT

180 mm

GPU MAX LENGTH

420 mm

I/O PANEL

USB 3.0 x 2, Type-C x 1, HD Audio

PCI CARD SLOT

7

FAN SUPPORT

Front: 3 x 120 mm
Top: 3 x 120 mm / 2 x 140 mm
Rear: 1 x 120 mm
Bottom: 2 x 120 mm

LIQUID COOLING SUPPORT

Top: 360 mm, 280 mm

POWER SUPPLY SUPPORT

Bottom mounted 220 mm

WEIGHT

N.W.: 6.8 kg
G.W.: 8.2 kg
